DA 2000
34 Technical User Guide
437155 437156 437158 437157
Electrical
Voltage
V 1x220 3x230 3x400 3x400
Operating voltage
V AC 210-230 220-240 380-415 380-415
Frequency
Hz 60 50
Current consumption
A 17 11.1 6.4 6.4
Input power P1
kW 3.7 3.6 3.6 3.6
Input power P2 shaft
kW 3
Mechanical
Volume
l/min 18.5 18.5 18.5 21
Min. flow
% 20
Max. pressure
bar 70
Working pressure
bar 70
Capacitor
μF 80 - - -
Min. pressure water supply at
max. capacity
bar 2
Standard filters
micron 1 and 5
Coarse filter (auxilliary equip-
ment)
micron 25 - 10
Sound pressure level (incl.
Cover) at 100 % performance
dB 79
Oil type (mineral oil)
SAE 15W-40
Environment
Temperature, operation
°C 0 to +40
Storage temperature
°C 0 to +40
Ambient humidity, operation
%RH 85
Protection class
IP 54
Shipment
Dimension HxWxD
mm 716x571x467
Dimensions when packed
HxWxD
mm 800x600x550
Weight
kg 49.2 49.6 49.6 49.6
Shipping weight
kg 51.2 51.6 51.6 51.6
