Skov DA 2000 - 8 Technical Data; Specifications: Pumps Without Frequency Converter

DA 2000
Technical User Guide 33
8 Technical data
8.1 DA 2000 pumps without frequency converter
437150 437151 437152 437153 437154
Electrical
Rated voltage
V 1x230 3x400 1x230 3x230 3x400
Operating voltage
V AC 220-240 380-415 220-240 220-240 380-415
Frequency
Hz 50 50/60 50 50/60 50/60
Current consumption
A 9.5 3.6 14 9.4 5.4
Input power P1
kW 2.2 1.9 3.2 3 3
Input power P2 shaft
kW 1.5 1.5 2.2 2.2 2.2
Mechanical
Volume
l/min 6 6/7 12 12/14 12/14
Min. flow
% 15
Max. pressure
bar 70
Working pressure
bar 70
Capacitor
μF 40 - 65 - -
Min. pressure water supply at
max. capacity
bar 2
Standard filters
micron 1 and 5
Coarse filter (auxilliary equip-
ment)
micron 25 - 10
Sound pressure level (incl.
Cover) at 100 % performance
dB 79
Oil type (mineral oil)
SAE 15W-40
Environment
Temperature, operation
°C 0 to +40
Storage temperature
°C 0 to +40
Ambient humidity, operation
%RH 85
Protection class
IP 54
Shipment
Dimension HxWxD
mm 716x571x467
Dimensions when packed
HxWxD
mm 800x600x550
Weight
kg 41 41 50.5 43.6 43.6
Shipping weight
kg 43 43 52.5 45.6 45.6
