DA 2000
6 Technical User Guide
2 Product survey
437150 Pump V2 6 l/min 1x230V 50Hz
437151 Pump 6/7 l/min 3x400V 50/60Hz
437152 Pump V2 12 l/min 1x230V 50Hz
437153 Pump 12/14 l/min 3x230V 50/60Hz
437154 Pump 12/14 l/min 3x400V 50/60Hz
437155 Pump V2 18.5 l/min 1x220V 60Hz
437156 Pump V2 18.5 l/min 3x230V 60Hz
437158 Pump V2 18.5 l/min 3x400V 60Hz
437157 Pump V2 21 l/min 3x400V 50Hz
The pump is an ON/OFF pump and is supplied as a complete unit for
mounting on the wall and includes filters, electronic thermal circuit breaker,
pressure sensor, safety valve, bleed screws, manometer, solenoid valve,
high-pressure hose, etc.
The pump is used where the lowest rate of flow at partial load exceeds 15
% (6/7/12/14 l pump) or 20 % (8,5/21 l pump) of the max. capacity. This
means, for example, that the minimum flow is 0.9, 1.8 and 3.7/4.2 l/min. for
the pumps supplying 6, 12 and 21 l/min. respectively at 50 Hz. If this cannot
be met, choose a pump with frequency converter - listed below.
The pump is supplied including mounting kit.
The mounting kit includes:
2 x drain ball valve, 12 mm pipe
1 x straight connector
1 x T-connector
1 x drain plug valve ¾"
2 x threaded rod M10, 495 mm
3 x dowel 10 mm
3 x coach screw 10x70
2 x washer 6x14
4 x nut M10
1 x hose ¾" with collar band
1 x hose 5/8" with collar band
4 x spacer ø20/ø5x20 mm
4 x chipboard screw 5x70
4 x pipe holder 10 mm
4 x dowel 6 mm
