Sky Control SC8100 - Web Interface Overview

Sometimes, in case of loss of all the data on
the appliance or if you have equipment with
unknown settings, it is may be necessary to
restore the password identier and change it to
a “guest”. Use the le “sky25resetusers.sky”,
copy this le to the root of a USB-ash drive,
without changing the le name. Plug the USB
ash drive into the appliance socket “USB” and
wait. The update process is displayed on the
front panel with ashing LED “ERR”. If success-
ful, the “ERR” LED will go off, and “ACT” LED
will blink for a while with increased frequency. If
unsuccessful “ERR” LED will remain lit. Remove
USB-ash drive and reboot the system. Test
the appliance.
Password recovery
1. “Toolbar”. Includes
Menu to create groups, notications and virtual
devices
• Menu to manage the interface appear-
ance
• “Refresh” button for updating the ele-
ment data
• Floor map - structural tree for system
elements designed for structural organi-
sation of the elements by the user.
• System map - functional tree for system
elements. It is intended for the functional
organization of the user device
• Properties - properties of elements. It is
designed to congure a system element
that the user has selected in the tree;
Interface overview
Control of the device is made through Sky
Control web-interface. The general view of the
interface is shown below:
28
Initial Conguration
“USB” and wait. The update process is displayed
on the front panel with ashing LED “ERR”.
If successful, the “ERR” LED will go off, and
“ACT” LED will blink for a while with increased
frequency. If unsuccessful “ERR” LED will remain
lit. Remove USB-ash drive and reboot the
system. Test the appliance.
2. Tab “Floor map”
• Cameras panel. For pictures transmitted
from the camera.
• Map/plan panel . Designed for visual
placement of elements on the plan/map
3. Tab “Outlets” for control of outlets
4. Tab “Graphs” for comparative analysis of
the history of sensor readings;
5. Tab “Preferences” for setting the param-
eters of the device. It includes:
• “
Logic schemes”. To set automatic actions
on events happening in the system;
• “Users”. To manage user accounts and
permissions;
• “Access control”. To manage access keys;
• “CAN cong”. To control CAN devices;
• “Network”. To dene network settings;
• “Settings”. To dene interface settings;
6. “System menu”. Includes options for serv-
ice management of the device.
7. “Sensors”. For placement of sensors and
minigraphs
8. “System info”. Contains information about
the version of the web interface, the current
time and the operating time of the device.
9. “Log bar”. To view system log
10. “Status bar”. It is designed to display cur-
rent information, as well as to congure the web
interface;
In order to save the settings of the ele-
ments and logic schemes into the ash
memory of the device go to System menu-
>Save setting to ash.
