Sky Control SC8100 - Dry Contacts Module

To avoid breakage, do not connect the
relays loads when the appliance is
turned on.
Connecting dry contacts
module
SC8100, SC8110, SC2110, SC2100 have the
possibility to install Dry Contacts module. It is a
device mounted and connected inside of master
unit. Can be used together with any contacts,
for example with door or window contacts,
circuit breakers etc.
Inventory
Components
Dry contacts board BH10 cable
Relay terminal plugs Screw M3*5mm
21
Installation
Allows to control 16 dry contacts.
