9 “A1..A8” - 8 RJ12 analog sensor inputs
with auto-sensing.
10 “SIM” - connector with an ejector, used
when GSM modem is installed inside of the
appliance to connect SIM card.
11
“Outputs 1..4” - 4 relays status indicators.
12 “1-Wire” - RJ9 connector for 1-Wire
Proximity type or I-touch readers with
auto-sensing.
13 “SMA” - connector, used when GSM mo-
dem is installed inside of the appliance to
connect GSM antenna.
14 “PWR” - for connection of external power
12V. Internal input “+”.
Back panel SC8100
Back panel SC8110
Back panel SC2110
10
Physical description
