SECTION 6, Page 49SJ-800 Series E Battery Powered
119153
Figure 6.2-5. Lift Cylinder Manifold Assembly
AN
1 106688 1 BLOCK, Manifold with plugs
111316 1 •BLOCK,Manifold
108052 1 •PLUG,Expander
2 106557 1 VALVE, Relief
3 107269 1 VALVE, Holding valve (N.C.)
4 114578 1 FITTING, Hydraulic elbow
5 103403 1 SEAL, O-ring
6 120481 1 ORIFICE, One way (0.104” Dia.)
7 104493 1 COIL, 24V
8 103931 4 BOLT, Socket (5/16”-18 x 2” Grade 5)
9 104637 4 WASHER, Lock (5/16” high collar 0.09)
10 103996 4 WASHER, Flat (5/16”)
Index
No.
Skyjack
Part No.
Description Qty.
To Next Page
