Skyjack SJ 8831E - 17. Outrigger Circuit Inoperative

SECTION 4, Page 9SJ-800 Series E Battery Powered
119153
Troubleshooting Information - Electrical System
13. Defective Coil (4H-27) or (4H-27A).
-Check coil. Replace if defective.
14. Open or defective Diode (D27) or (D27A).
-Check diode. Replace if defective.
4.1-17. Outrigger Circuit Inoperative (Optional)
1. Open or defective Outrigger Enable Relay (10ACR).
-Check relay. Replace if defective.
2. Loose or broken wire #09 to Outrigger Enable Relay (19CR).
-Check continuity. Replace if defective.
3. Loose or broken wire #09A to Outrigger Toggle Switches (S20,S21,S22 or S23).
-Check continuity. Replace if defective.
4. Open or defective Outrigger Toggle Switches (S20, S21, S22 or S23).
-Close switch. Replace if defective.
5. Loose or broken wire #17A or #02 on Coil (2H-17A).
-Check continuity. Replace if defective.
6. Defective Coil (2H-17A).
-Check coil. Replace if defective.
7. Loose or broken wire #71, #72, #73, #74, #75, #76,#77, #78 or #02 on Outrigger Coils.
-Check continuity. Replace if defective.
8. Defective Coil (4H-71, 4H-72, 4H-73, 4H-74, 4H-75, 4H-76, 4H-77 or 4H-78).
-Check coil. Replace if defective.
9. Open or defective Limit Switch (LS61, LS62, LS63 or LS64).
-Make sure Outriggers are fully retracted. Check switch. Replace if defective.
10. Open or defective Lift Enable Relay (61CR-2).
-Check relay. Replace if defective.
11. Open or defective Limit Switch (LS65, LS66, LS67 or LS68).
-Make sure Outriggers are fully retracted. Check switch. Replace if defective.
12. Open or defective Lift Enable Relay (65CR).
-Check Relay. Replace if defective.
13. Open or defective Limit Switch (LS61, LS62, LS63 or LS64).
-Make sure Outriggers are fully retracted. Check switch. Replace if defective.
14. Open or defective Drive Enable Relay (61CR-1).
-Check relay. Replace if defective.
