SECTION 6, Page 53SJ-800 Series E Battery Powered
119153
Parts list continued from the previous page.
7 (Ref.) 1 AXLE ASSEMBLY, Rear drive
- (For Components, Refer to Figure 6.3-11)
  123855 8 •BOLT,Hex-hd1/2”-13x2-3/4”grade8
  126286 8 •WASHER,Lock1/2”heavyduty
  123856 8 •NUT,Hex-hd1/2”-13grade8
8 124342 1 KIT, Emergency Lowering Access Bar
  132477 1 •BARASSEMBLY,EmergencyLoweringAccess(ANSI/CSA)
  108767 1 •BARASSEMBLY,EmergencyLoweringAccess(CE)
  119920 2 •CLIP,Spring
  103964 2 •BOLT,Machine#10-32x1/4”
  124160 2 •PIN,Locking
9 (Ref.) 1 BATTERY ROLL-OUT TRAY ASSEMBLY
(For Components, Refer to Figure 6.3-12)
10 117317 1 WELDMENT, Base
123547 1 WELDMENT, Base (w/Scissor Guard option)
Use Part # 117318 for Machines with Serial # 37007 (8831) or
42123 (8841) and below.
117320 1 WELDMENT, Base (w/Outrigger option)
123806 1 WELDMENT, Base (w/Scissor Guard & Outrigger option)
Use Part # 117319 for Machines with Serial # 37007 (8831) or
42123 (8841) and below.
11 (Ref.) 1 SWITCH, End-of-stroke limit
- (For Components, Refer to Figures 6.6-6 & 6.6-7)
12 (Ref.) 1 HYDRAULIC/ELECTRIC CABINET ASSEMBLY
- (For Components, Refer to Figure 6.5-1)
13 151977 2 LADDER (Model 8831E)
151979 2 LADDER (Model 8841E)
  103473 8 •BOLT,Hex-hd3/8”-16x1”lg.
  103472 16 •WASHER,Flat3/8”
  103999 8 •WASHER,Lock3/8”
  103978 8 •NUT,Hex3/8”-16
14 (Ref.) 1 HYDRAULIC OIL TANK/CHARGER CABINET ASSEMBLY
- (For Components, Refer to Figure 6.4-2)
  103473 8 •BOLT,Hex-hd3/8”-16x1”lg.
  103472 16 •WASHER,Flat3/8”
  103999 8 •WASHER,Lock3/8”
  103978 8 •NUT,Hex3/8”-16
15 (Ref.) 4 LEG, Outrigger (Machines with Outrigger Option)
- (For Components, Refer to Figures 6.7-1)
16 123760 1 STRAP, Static Assembly (EE Rated)
  123752 2 •STRAP,Static
  101632 1 •BOLT,3/8”-16x.75
  103999 1 •WASHER,3/8”Lock
Figure 6.3-1. Base, Axles And Wheels (Continued)
Index
No.
Skyjack
Part No.
Description Qty.
