SECTION 6, Page 123SJ-800 Series E Battery Powered
119153
Figure 6.7-2. Hydraulic Outrigger Option - Hydraulic Hose Connections
Index
No.
Skyjack
Part No.
Description Qty.
1 (Ref.) 1 MANIFOLD ASSEMBLY, Outrigger
- (For Components, Refer to Figure 6.7-4)
2 (Ref.) 4 CYLINDER ASSEMBLY, Outrigger
- (For Components, Refer to Figures 6.7-3)
3 103069 8 FITTING, Connector #6orb-#6
4 130843 8 HOSE ASSEMBLY, Outrigger cylinder
(Order P/N 106330 for machines with Serial No. 37406 (8831E),
43044 (8841E), and Below)
5 102554 2 HOSE ASSEMBLY, Main manifold to outrigger manifold
6 112062 1 TUBE ASSEMBLY, Left front retract
7 112063 1 TUBE ASSEMBLY, Right front retract
8 112064 1 TUBE ASSEMBLY, Left rear retract
9 112065 1 TUBE ASSEMBLY, Right rear retract
10 112066 1 TUBE ASSEMBLY, Left rear extend
11 112067 1 TUBE ASSEMBLY, Right rear extend
12 112068 1 TUBE ASSEMBLY, Right front extend
13 112069 1 TUBE ASSEMBLY, Left front extend
14 118216 1 COVER, Outrigger manifold
15 102085 10 CLAMP, Double tube 3/8”
To Next Page
