Skyjack SJ 8831E - Page 190

SECTION 6, Page 133SJ-800 Series E Battery Powered
119153
1 116506 1 FRAME, RH Front side scissor guard
  116525 1 •MESH,RHFrontscissor
  103883 4 •BOLT,Hex-hd5/16-18Gr.5
  103984 4 •NUT,LockHex5/16”-18Gr.B
  103996 4 •WASHER,Flat5/16”
2 116528 1 FRAME, RH Rear side scissor guard
  116530 1 •MESH,RHRearscissor
  103883 4 •BOLT,Hex-hd5/16-18Gr.5
  103984 4 •NUT,LockHex5/16”-18Gr.B
  103996 4 •WASHER,Flat5/16”
3 116527 1 FRAME, LH Front side scissor guard
  116525 1 •MESH,LHFrontscissor
  103883 4 •BOLT,Hex-hd5/16-18Gr.5
  103984 4 •NUT,LockHex5/16”-18Gr.B
  103996 4 •WASHER,Flat5/16”
4 116529 1 FRAME, LH Rear side scissor guard
  116530 1 •MESH,LHRearscissor
  103883 4 •BOLT,Hex-hd5/16-18Gr.5
  103984 4 •NUT,LockHex5/16”-18Gr.B
  103996 4 •WASHER,Flat5/16”
Use the following hardware on side guards for Machines with
Serial number 37007 (8831) or 42123 (8841) and below.
103871 4 •BOLT,Hexhd3/8”-16x1-3/4”
  103596 4 •BOLT,Hexhd3/8”-16x2”
  103978 8 •NUT,Hex3/8”-16
5 116562 1 FRAME, Front scissor guard, (Model 8831)
116548 1 FRAME, Front scissor guard, (Model 8841)
  116546 1 •MESH,Fronttop,(Model 8841)
  116547 1 •MESH,Frontelbow
  101632 8 •BOLT,Hex-hd3/8”-16x3/4”lg.
  103999 8 •WASHER,Lock3/8”
  103472 8 •WASHER,Flat3/8”
6 116566 1 FRAME, Rear scissor guard, (Model 8831)
116542 1 FRAME, Rear scissor guard, (Model 8841)
  116565 1 •MESH,Rear,(Model 8831)
  116541 1 •MESH,Rear,(Model 8841)
  101632 8 •BOLT,Hex-hd3/8”-16x3/4”lg.
  103999 8 •WASHER,Lock3/8”
  103472 8 •WASHER,Flat3/8”
7 116535 4 FRAME, Corner, (Machines without Outriggers)
  116536 4 •MESH,Rear
8 100702 20 CAP, Tube end
9 116434 2 BUMPER
Use Part # 116438 for Machines with Serial #37007 (8831) or
42123 (8841) and below.
Part list continued on the next page.
Figure 6.7-7. Scissor Guard Option
Index
No.
Skyjack
Part No.
Description Qty.
