SECTION 3, Page 7SJ-800 Series E Battery Powered
119153
Figure 3.2-1. Hydraulic Schematic Parts List
Index
No.
Skyjack
Part No.
Description Qty.
C1 109953 1 CYLINDER, Lift
C2 109953 1 CYLINDER, Lift
C3 120275 1 CYLINDER, Front extension platform
Use Part # 118090 for Machines with Serial # 36839 (8831)
or 41670 (8841) and below.
C4 120275 1 CYLINDER, Rear extension platform
Use Part # 118090 for Machines with Serial # 36839 (8831)
or 41670 (8841) and below.
C5 112448 1 CYLINDER, Disc brake
C7 112498 1 CYLINDER, Steer
C9-C12 132694 1 CYLINDER, Outrigger
Order the following as per Serial Breakdown below:
1. 126091 - Serial No. 37315 to 37406 (8831E), or 42703 to 43044 (8841E)
2. 120309 - Serial No. 36840 to 37314 (8831E), or 41671 to 42702 (8841E)
3. 115646 - Serial No. 36839 (8831E), or 41670 (8841E), & Below
CV1 104567 1 VALVE, Check
CV2 104567 1 VALVE, Check
CV3 104567 1 VALVE, Check
CV4 104567 1 VALVE, Check
CV5 104567 1 VALVE, Check
CV6 104567 1 VALVE, Check
CV7 104115 1 VALVE, Check
CV8 104115 1 VALVE, Check
CV9 104115 1 VALVE, Check
CV10 104115 1 VALVE, Check
F1 109568 1 FILTER
104254 1 •ELEMENT,Filter
HP2 110652 1 PUMP, Hand
M1 109311 1 MOTOR, Center drive hydraulic
M2 113875 1 MOTOR W/FLOW CONTROL, Hyd. generated
MB1 108804 1 MANIFOLD, Main
MB3 106688 1 MANIFOLD, Holding valve
MB4 106688 1 MANIFOLD, Holding valve
MB5 107382 1 MANIFOLD, Powered platform
MB6 119748 1 MANIFOLD, Lift
MB7 116586 1 MANIFOLD, Quick brake
MB8 111970 1 MANIFOLD, Outrigger
MC1 110434 1 MOTION CONTROL ASSEMBLY
O1 114218 1 ORIFICE, Controller lowering .70
O2 120481 1 ORIFICE, Lowering .104
O3 120481 1 ORIFICE, Lowering .104
O4 120756 1 ORIFICE, Lowering .149
O5 116725 1 ORIFICE, Emergency lowering .067
O6 123853 1 ORIFICE, Dump Valve 0.031
OC1 114284 1 OIL COOLER ASSEMBLY, Hydraulic generator option
P1 119999 1 PUMP, (Gearbox)
P2 700669 1 PUMP, (Hydraulic tray)
P3 113173 1 PUMP, Hydraulic 1.2gpm powered extension platform
PS1 102863 1 PRESSURE, Switch
Parts list continued on the following page.
