SECTION 3, Page 16 SJ-800 Series E Battery Powered
119153
Figure 3.4-1. Electrical Schematic And Diagram Parts List (Continued)
Index
No.
Skyjack
Part No.
Description Qty.
Parts list continued from the previous page.
17ACR 108589 1 RELAY, Outrigger lift disable
18ACR 108589 1 RELAY, Small pump
21CR-1 108589 1 RELAY, Power deck interlock
21CR-2 108589 1 RELAY, Pump interlock
25CR 108589 1 RELAY, Quick brake
28CR 108589 1 RELAY, Tilt
30CR 108589 1 RELAY, Brake
32CR 108589 1 RELAY, Lift sensor
33CR 108589 1 RELAY, Traction sensor
59ACR 108589 1 RELAY, Speed signal
60CR1 108589 1 RELAY, 24 Volt (auxiliary down relay) (CE)
60CR2 108589 1 RELAY, 24 Volt (auxiliary reverse relay) (CE)
60CR3 108589 1 RELAY, 24 Volt (auxiliary forward relay) (CE)
60ECR1 108589 1 RELAY, 24 Volt (down relay) (CE)
60ECR2 108589 1 RELAY, 24 Volt (reverse relay) (CE)
60ECR3 108589 1 RELAY, 24 Volt (forward relay) (CE)
61CR 108589 1 RELAY, Drive enable (CE)
61CR-1 108589 1 RELAY, Drive enable
61CR-2 108589 1 RELAY, Lift enable
65CR 108589 1 RELAY, Lift enable
OCM1 132804 1 MODULE, Outrigger Auto-Levelling Controller
2H-13-1 105610 1 COIL, Lowering
2H-13-2 104493 1 COIL, Holding
2H-13-3 104493 1 COIL, Holding
2H-13B-1 105610 1 COIL, Lowering
2H-13B-2 104493 1 COIL, Holding
2H-13B-3 104493 1 COIL, Holding
2H-14D 105610 1 COIL, Lift
2H-17A 103605 1 COIL, Outrigger holding
2H-21A 105610 1 COIL, System dump
2H-25 103605 1 COIL, Quick brake
2H-30 105610 1 COIL, Brake release
2H-44 105610 1 COIL, Gearbox holding
4H-23 107439 1 COIL, Right steer (Vickers)
128320 1 COIL, Right steer (Hytos)
4H-24 107439 1 COIL, Left steer (Vickers)
128320 1 COIL, Left steer (Hytos)
Parts list continued on the following page.
