Skyjack SJ 8831E - Page 36

SECTION 3, Page 20 SJ-800 Series E Battery Powered
119153
Figure 3.4-3b. Control Box Diagram - ANSI/CSA & CE Equipped With All Options
(Refer to Serial No. Reference Chart)
M50087AC
Refer to following page(s) to locate
serial no. and respective diagram.
Figure 3.4-3a.
60523AA
Serial Breakdown Reference Chart
Model Serial Number
8831E 37315 & Above
8841E 42702 & Above
AN
