Directional valve mounting bolts 28-32 lbf.in 2.16 – 3.61 Nm
Wheel mounting bolts 135-145 lbf.ft 183.06-196.62 Nm
Cartridge
Size
Torque 08 38 58 10 12 16
Lbf.ft (max) 20 20 20 25 35 50
Lbf.in (max) 240 240 240 300 420 600
Nm (max) 27.12 27.12 27.12 33.90 47.46 67.80
Coils
Size
Torque All coils
Lbf.ft (max) 4 to 5
Lbf.in (max) 48 to 60
Nm (max) 5.42 to 6.78
SAE Plugs
Size
Torque 2 4 5 6 8 10 12 16
Lbf.ft (max) 3 10 15 15 25 25 30 35
Lbf.in (max) 36 120 180 180 300 300 360 420
Nm (max) 4.07 13.56 20.34 20.34 33.90 33.90 40.68 47.46
Newton-meter = Nm Pound-force foot = lbf.ft Pound-force inch = lbf.in
60284AA
WARNING
Air Pressure Can Affect Stability. Temperature Changes Can Affect Air Pressure. It Is Important To Check Tire Pressures Prior To
Use On A Daily Basis In The Operating Conditions Experienced By End User. If The Measured PSI Reading Is Less Than The
Specification And Tolerance, Re-inflate To The Proper Specification Within The Tolerance Range Specified. Tires Shall Also Not
Be Subject To Over-Inflation Above The Recommended Specification And Tolerance Range.
Tire* Fill Specification
Pressure
Psi (kPa)
Size Fill Type Ply Rating
Factory
Listed Sidewall
Maximum
#6 30-10-16.5 NHS 8 50 (344.7)* 65 (448.2)
#6 32.3-10-16.5 HD Stabilizer 10 70 (482.6)* 75 (517.1)
#6 30-10-16.5 OTR Outrigger 10 70 (482.6)* 75 (517.1)
#7 31-15.5-15 NHS 8 50 (344.7)* Not Available
#8 31-13.5-15 NHS Consult Skyjack Inc.
#6 31-10-16.5 “Carlisle”
Air
10 75 (517.1)* Not Available
#6 31-10-16.5 “Carlisle” 10 ***
#6F 30-10-16.5 NHS 8 **
#7F 31-15.5-15 NHS 8 **
#8F 31-13.5-15 NHS
Solid
Urethane
Consult Skyjack Inc.
*
**
***
Factory preset @ 20°
C, Check pressures regularly as tires can lose pressure over time and over different ambient temperatures
even under normal conditions.
Urethane used for filling #6F and #7F tires MUST be 50-55 durometer.
Urethane used for filling #6 “Carlisle” tires MUST be 32 durometer.
60035AB
