Page 23

Item Part No. Description Qty.

1 B2-450-03-1 JUNCTION BOX ASSEMBLY ...................................................................................... 1

2 B9-210-43 SCREW, phillips, M4 x8 w/washers ............................................................................ 2

3 B2-450-04 CEILING COVER (LFS models) .................................................................................. 1

B2-450-04-1 CEILING COVER (LFSLFS models) ............................................................................ 1

4 B2-450-05 SUPPORT HUB (LFS models) ..................................................................................... 1

B2-450-06 SUPPORT HUB (LFSLFS models) .............................................................................. 1

5 B2-450-07 BOLT, allen, M8 x30 .................................................................................................... 2

6 B2-450-08 TAPERED ROLLER BEARING ASSEMBLY .............................................................. A/R

7 B2-450-10 COLLAR, stop .............................................................................................................A/R

8 B2-450-09 BOLT, allen, M5 x10 ................................................................................................... A/R

9 B2-450-11 JOINT SHAFT (LFS models) ........................................................................................ 1

B2-450-12 JOINT SHAFT (LFSLFS models) ................................................................................. 1

10 ----- SPINDLE (specify model) ............................................................................................1

11 B2-450-13 BOLT, allen, M8 x15 .................................................................................................... 2

12 B2-450-14 RADIAL ARM, 43.0” ....................................................................................................A/R

B2-450-15 RADIAL ARM, 50.6” (LFS models) ............................................................................. A/R

B2-450-16 RADIAL ARM, 50.6” (LFSLFS models) ....................................................................... A/R

13 B2-450-17 BRAKE SCREW .......................................................................................................... A/R

14 B3-210-12 SCREW, allen, countersunk, M6 x 12 ........................................................................ A/R

15 B2-450-19 STOP, ball, 8mm .........................................................................................................A/R

16 B2-450-20 PLATE, stop ................................................................................................................ A/R

17 B2-450-21 SCREW, allen, countersunk, M5 x12 .........................................................................A/R

18 B2-450-22 TAPERED ROLLER BEARING ASSEMBLY ............................................................... 2

19 B2-450-23 BEARING BODY .......................................................................................................... 1

20 B2-450-24 NUT, retainer ................................................................................................................ 1

21 B2-450-25 SCREW, set, M5 x 8 ..................................................................................................... 2

22 B1-420-05 CIRCUIT BOARD, VFB ............................................................................................... A/R

23 H7-010-47 CABLE, coaxial, RG59U, 50' ...................................................................................... A/R

24 B2-451-36 SCREW, phillips, countersunk, M4 x 6 ....................................................................... A/R

25 B2-451-35 STAND-OFF ................................................................................................................ A/R

1. HUB AND RADIAL ARM ASSEMBLY
