SYSTEM COMPONENTS
FIXTURE
JUNCTION BOX
CAMERA
B1-710-56
COUNTERWEIGHT
B1-710-66
STERILIZABLE
CAMERA COVER
B1-710-57
POWER CORD FOR
CAMERA CONTROL UNIT
B9-211-04
VIDEO “OUT” (COAXIAL CABLE (3) CONNECTOR) B1-710-04
CAMERA CONTROL UNIT B1-710-59
COAXIAL CABLE (4) CONNECTOR B1-710-03
3/4” METAL CONDUIT 120VAC, 15A INPUT DEDICATED
3/4” METAL CONDUIT 12AWG, 3 WIRES PER LIGHTHEAD RED, GREEN, WHITE 30VDC OUTPUT
1” METAL CONDUIT
FOR OPTIONAL CAMERA
SYSTEM CONTROL
(SUPPLIED BY OTHERS)
65’ CAMERA CONTROL
CABLE W/FACEPLATE
& CONNECTOR
(SKYTRON SUPPLIED)
B1-710-02
WALL CONTROL
(SKYTRON SUPPLIED)
TO BE MOUNTED NEAR
ENTRANCE DOOR OR
AT N.D.C.
CAMERA CONTROL
JUNCTION BOX 2” X 4”
(SUPPLIED BY OTHERS)
TYPICAL LOCATION: • NURSE DOCUMENTATION CENTER • CABINET • SHELF
