Skytron AURORA LED Series User Manual

INTRODUCTION
 Thismanualcontainstheexplodedviewsandreplacementpartslistsfortheserviceablecomponents
oftheSKYTRONAURORAIISeriesSurgicalLightingxtures
 Eachserviceablepartintheseexplodedviewsisidentiedbyareferencenumber.Usethisnumber
tolocatenecessarypartinformationinthepartslistadjacenttotheexplodedview.
Always use the complete SKYTRON part number and description when ordering replacement
parts.
Abbreviations
As Required ....................................................... A/R
Optional .............................................................. opt
Serial Number ................................................... S.N.
Not Shown ........................................................... NS
Althoughcurrentattimeofpublication,SKYTRON’spolicyofcontinuousdevelopmentmakesthis
manualsubjecttochangewithoutnotice.
The lighthead Data Labels contain the lighthead
model number, bulb type, fuse type, electrical specifications
and product serial number.
LIGHTHEAD LABEL
WALL CONTROL LABEL
Manufactured for SKYTRON by DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
GRAND RAPIDS, MI · 616.656.2900
INPUT 120V~240V AC
CAT. NO.
ELECTRICAL RATING
OUTPUT 30V DC
SERIAL NO. 0000
SAFETY FUSE TIMELAG
Manufactured for SKYTRON by DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
GRAND RAPIDS, MI · 616.656.2900
INPUT
CAT. NO.
LIGHTHEAD
ELECTRICAL RATING
LED SOURCE
SERIAL NO. 0000
30V DC
MODEL
(CAT. NO.)
SERIAL NO.
