Page 13

Item Part No. Description Qty.

3. FOCUS MECHANISM ASSEMBLY

1 B9-610-42 LABEL, focus control.................................................................................................... 1

 2 B9-610-41 SCREW,M4x12 ......................................................................................................... 1

3 B1-610-34 KNOB, focus ................................................................................................................ 1

 4 B1-010-37 SCREW,set,M4x8 .................................................................................................... 2

 5 B9-610-40 WASHER,wave ........................................................................................................... 1

6 B9-610-35 SUPPORT, focus shaft ................................................................................................. 1

7 B1-710-26 FRONT FACE, AUR5 ................................................................................................... 1

B1-710-52 FRONT FACE, AUR7 ................................................................................................... 1

8 B9-610-37 LINER .......................................................................................................................... 1

9 B9-610-36 WASHER ..................................................................................................................... 1

10 B9-610-38 NUT .............................................................................................................................. 1

11 B9-610-33 COLLAR ....................................................................................................................... 1

12 B9-610-34 SCREW, set ............................................................................................................. A/R

13 B9-610-39 GEAR SHAFT C .......................................................................................................... 1

14 B9-610-28 SCREW, set ............................................................................................................. A/R

15 B1-420-70 UNIVERSAL JOINT ..................................................................................................... 1

16 B9-610-31 GEAR SHAFT B, LED5, AUR5 .................................................................................... 1

B9-610-32 GEAR SHAFT B, LED7, AUR7 .................................................................................... 1

17 B9-610-24 GEAR SHAFT A, LED5, AUR5 .................................................................................... 1

 18 B9-610-80 SCREW(A),M4x8w/washers ............................................................................... A/R

 19 B9-610-27 SCREW(B),M4x8w/washers ............................................................................... A/R

20 B9-610-26 MOUNT, focus rod, LED5, AUR5 ................................................................................. 1

B9-610-25 MOUNT, focus rod, LED7, AUR7 ................................................................................. 1

21 B9-610-23 PILLOW BLOCK .......................................................................................................... 1

22 B1-410-56 GEAR, pinion ............................................................................................................... 1

23 B1-410-57 E-RING ........................................................................................................................ 1

24 B1-610-29 MOUNT, focus ring, AUR5 ........................................................................................... 1

B1-610-26 MOUNT, focus ring, AUR7 ........................................................................................... 1

 25 B9-610-19 SCREW,M3x6,LED7,AUR7 ................................................................................. A/R

26 B9-610-29 MOUNT, focus rod, LED7, AUR7 ................................................................................. 1

27 B1-610-20 FRAME, inner support ................................................................................................. 1

28 B9-710-19 GEAR SHAFT A, LED7, AUR7 .................................................................................... 1

Skytron AURORA LED Series User Manual
