Page 15
Item Part No. Description Qty.
4. BALANCE MECHANISM ASSEMBLY, AUR5
B3-610-12 BALANCE MECHANISM ASSEMBLY, AUR5 .......................................................... A/R
1 B9-310-06 SCREW, set ............................................................................................................. A/R
2 B3-310-01 VERTICAL SUPPORT TUBE ................................................................................... A/R
3 B3-210-05 BRUSH BLOCK, VST.................................................................................................. 1
4 B3-310-13 MOUNT, brush block .................................................................................................... 1
5 B3-210-04 SLIP RING ................................................................................................................... 1
6 B9-210-28 SCREW,phillipshead,M4x8 ..................................................................................... 4
7 B9-210-69 WASHER, M4 .............................................................................................................. 4
8 B3-310-12 NUT .............................................................................................................................. 1
9 B3-210-11 BEARING ..................................................................................................................... 1
10 B3-210-13 SLEEVE, VST .............................................................................................................. 1
11 B3-210-12 VSTSCREW,M6x12 ............................................................................................. A/R
12 B3-310-02 PLUG, chrome ............................................................................................................. 1
13 B3-210-14 WASHER, needle bearing............................................................................................ 2
14 B3-210-15 BEARING, needle ........................................................................................................ 1
15 B3-710-43 JOINT, upper knuckle ................................................................................................... 1
16 B9-210-82 SCREW, set ................................................................................................................. 1
17 B3-210-34 PIN,pivot ..................................................................................................................... 2
18 B3-210-32 WASHER, bearing ....................................................................................................... 4
19 B3-210-33 BEARING ..................................................................................................................... 2
20 B9-210-81 SCREW,allenhead,M5x25 ...................................................................................... 2
21 B3-710-10 GUIDE, bearing, right .................................................................................................. 1
B3-710-11 GUIDE, bearing, left ..................................................................................................... 1
22 B3-210-28 COVER, side ................................................................................................................ 2
23 B9-210-79 SCREW,countersunk,allenhead,M5x10 ................................................................. 2
24 B3-210-30 RETAINER, bearing ..................................................................................................... 2
25 B3-210-31 BEARING ..................................................................................................................... 2
26 B3-210-29 PIN ............................................................................................................................... 1
27 B9-210-80 SCREW, countersunk, allen ......................................................................................... 6
28 B3-610-17 HOUSING, BOM lower................................................................................................. 1
29 B3-310-11 SCREW,countersunk,allenhead,M5x10 ................................................................. 3
30 B3-310-05 SHAFT, main spring ..................................................................................................... 1
31 B3-410-04 SPRING ....................................................................................................................... 1
32 B3-610-18 PLATE, nylon ............................................................................................................... 1
33 B3-310-10 WASHER, spring.......................................................................................................... 1
34 B3-310-09 COLLAR,adjustmentnut ............................................................................................. 1
35 B3-310-08 NUT,springadjustment ................................................................................................ 1
36 B3-410-03 SCREW ........................................................................................................................ 2
37 B3-420-08 COVER,adjustment ..................................................................................................... 1
38 B9-310-05 SCREW, phillips head .................................................................................................. 1
39 B9-310-04 SCREW, phillips head .................................................................................................. 4
40 B3-310-16 MOUNT, slip ring .......................................................................................................... 1
41 B3-610-19 ARM, yoke support ...................................................................................................... 1
42 B9-610-74 SCREW,countersunk,allenhead,M5x18 ................................................................. 1
To Next Page
