Page 17
Item Part No. Description Qty.
5. BALANCE MECHANISM ASSEMBLY, AUR7
B3-610-03 BALANCE MECHANISM ASSEMBLY, AUR7 .......................................................... A/R
1 B9-310-06 SCREW, set ............................................................................................................. A/R
2 B3-310-01 VERTICAL SUPPORT TUBE ................................................................................... A/R
3 B3-710-33 BRUSH BLOCK, BOM ................................................................................................ 1
4 B3-310-13 MOUNT, brush block .................................................................................................... 1
5 B3-210-04 SLIP RING ................................................................................................................... 1
6 B9-210-28 SCREW,phillipshead,M4x8 ..................................................................................... 4
7 B9-210-69 WASHER, M4 .............................................................................................................. 4
8 B3-310-12 NUT .............................................................................................................................. 1
9 B3-210-11 BEARING ..................................................................................................................... 1
10 B3-210-13 SLEEVE, VST .............................................................................................................. 1
11 B3-210-12 VSTSCREW,M6x12 ............................................................................................. A/R
12 B3-310-02 PLUG, chrome ............................................................................................................. 1
13 B3-210-14 WASHER, needle bearing............................................................................................ 2
14 B3-210-15 BEARING, needle ........................................................................................................ 1
15 B3-710-32 JOINT, upper knuckle ................................................................................................... 1
16 B9-210-82 SCREW, set ................................................................................................................. 1
17 B3-210-34 PIN,pivot ..................................................................................................................... 2
18 B3-210-32 WASHER, bearing ....................................................................................................... 4
19 B3-210-33 BEARING ..................................................................................................................... 2
20 B9-210-81 SCREW,allenhead,M5x25 ...................................................................................... 2
21 B3-710-24 GUIDE, bearing, right .................................................................................................. 1
B3-710-25 GUIDE, bearing, left ..................................................................................................... 1
22 B3-210-28 COVER, side ................................................................................................................ 2
23 B9-210-79 SCREW,countersunk,allenhead,M5x10 ................................................................. 2
24 B3-210-30 RETAINER, bearing ..................................................................................................... 2
25 B3-210-31 BEARING ..................................................................................................................... 2
26 B3-210-29 PIN ............................................................................................................................... 1
27 B9-210-80 SCREW, countersunk, allen head ................................................................................ 6
28 B3-610-08 HOUSING, BOM lower................................................................................................. 1
29 B3-310-11 SCREW,countersunk,allenhead,M5x10 ................................................................. 3
30 B3-420-04 SHAFT, main spring ..................................................................................................... 1
31 B3-710-44 SPRING ....................................................................................................................... 1
32 B3-710-34 PLATE, nylon ............................................................................................................... 1
33 B3-410-13 WASHER, spring.......................................................................................................... 1
34 B3-410-12 COLLAR,adjustmentnut ............................................................................................. 1
35 B3-410-11 NUT,springadjustment ................................................................................................ 1
36 B3-410-03 SCREW ........................................................................................................................ 2
37 B3-420-08 COVER,adjustment ..................................................................................................... 1
38 B3-610-10 ARM, yoke support ...................................................................................................... 1
39 B9-710-21 SCREW,set,M5x10 .................................................................................................. 3
40 B3-420-09 SCREW ........................................................................................................................ 1
41 B3-420-07 HOUSING, brush block ................................................................................................ 1
42 B9-610-74 SCREW,countersunk,allenhead,M5x18 ................................................................. 1
43 B3-210-05 BRUSH BLOCK, VST................................................................................................... 1
44 B9-410-12 SCREW,countersunk,allenhead,M5x15 ............................................................. A/R
45 B9-410-11 SCREW,countersunk,allenhead,M5x8 ............................................................. A/R
To Next Page
