Page 21
Item Part No. Description Qty.
7. LIGHTHEAD YOKE ASSEMBLY, AUR7
1 B1-610-07 COLLAR AND BEARING SHAFT ................................................................................ 1
2 B1-610-04 BEARING ..................................................................................................................... 1
3 B3-610-11 WASHER ..................................................................................................................... 1
4 B1-610-06 BEARING ..................................................................................................................... 1
5 B1-230-19 SCREW, brake ............................................................................................................. 1
6 B1-610-01 YOKE ........................................................................................................................... 1
7 B1-610-10 BEARING ..................................................................................................................... 1
8 B3-610-02 NUT .............................................................................................................................. 1
9 B9-610-52 SCREW, set ................................................................................................................. 1
10 B9-610-05 SNAP RING ................................................................................................................. 1
11 B3-710-38 SLIP RING, 7 YOKE ..................................................................................................... 1
12 B9-610-77 SCREW,M4x8,AUR7 ................................................................................................ 2
13 B1-610-11 MOUNT, slip ring .......................................................................................................... 1
14 B9-410-14 SCREW,set,M4x8conepoint ................................................................................... 1
15 B1-410-26 COVER, yoke ............................................................................................................... 1
16 B3-710-39 BRUSH BLOCK, 7 YOKE ............................................................................................. 1
17 B1-610-03 BRAKE SCREW .......................................................................................................... 1
18 B4-342-14 SCREW,M3x12 ......................................................................................................... 2
19 B1-410-06 WASHER, thrust bearing ............................................................................................. 2
20 B1-410-05 BEARING, thrust .......................................................................................................... 1
21 B3-220-13 BEARING, needle ........................................................................................................ 1
22 B4-230-11 SCREW,M4x4 ........................................................................................................... 4
23 B1-610-12 BEARING BODY .......................................................................................................... 1
24 B1-410-14 BEARING, needle ........................................................................................................ 1
25 B9-610-04 WASHER,wave ........................................................................................................... 3
26 B1-610-14 NUT .............................................................................................................................. 1
27 B9-610-76 SCREW,set,M4x4 .................................................................................................... 1
28 B1-610-17 COVER ........................................................................................................................ 1
29 B1-610-22 MOUNT, slip ring, AUR7 .............................................................................................. 1
30 B1-610-20 FRAME, inner support ................................................................................................. 1
31 B9-610-79 SCREW,M4x8 ........................................................................................................... 2
32 B9-610-78 SCREW,M4x12w/washers ....................................................................................... 1
33 B1-220-08 COVER, yoke ............................................................................................................... 1
34 B3-710-40 SLIP RING, 7LH ........................................................................................................... 1
