Page 49

Item Part No. Description Qty.

21. AUR STAND MODEL BASE ASSEMBLY

1 B9-610-59 TOUCH PAD, dimmer control assembly ....................................................................... 1

2 B9-611-22 COVER, base ............................................................................................................... 4

3 B4-242-49 NUT .............................................................................................................................. 4

4 B9-610-85 BASE ........................................................................................................................... 1

5 B4-242-50 WASHER, lock ............................................................................................................. 4

6 B4-341-32 CASTER ...................................................................................................................... 4

7 B9-610-86 CONNECTOR, male, 2-pin .......................................................................................... 1

8 B9-610-87 CONNECTOR, female, 2-pin ....................................................................................... 1

9 B9-610-88 CONNECTOR, male, 4-pin .......................................................................................... 1

10 B9-610-89 CONNECTOR, female, 4-pin ....................................................................................... 1

11 B4-342-58 CONNECTOR, male, 3-pin .......................................................................................... 1

12 B4-342-59 CONNECTOR, female, 3-pin ....................................................................................... 1

13 B9-610-90 CONNECTOR, female, 4-pin ....................................................................................... 1

14 B9-610-91 CONNECTOR, male, 4-pin .......................................................................................... 1

15 B9-610-82 CIRCUIT BOARD, 20,000 hour indicator ..................................................................... 1

16 B9-610-92 WIRE HARNESS, 2-wire ............................................................................................. 1

17 B9-610-93 CIRCUIT BOARD ......................................................................................................... 1

 18 B9-610-94 SCREW,w/at&lockwasher,phillips,M4x8 ......................................................... A/R

19 B9-610-95 CONNECTOR, male, 4-pin ...................................................................................... A/R

20 B9-610-96 CONNECTOR, male, 3-pin ...................................................................................... A/R

21 B9-610-97 CONNECTOR, female, 4-pin ................................................................................... A/R

22 B9-610-98 NOISE FILTER ............................................................................................................. 1

23 B9-610-99 FERRITE CORE .......................................................................................................... 1

24 B9-710-12 POWER SUPPLY UNIT ............................................................................................... 1

25 B9-611-02 HOUSING .................................................................................................................... 1

 26 B4-342-36 SCREW,phillips,M3x8 .............................................................................................. 2

27 B4-342-62 WASHER, star, M4 ................................................................................................... A/R

28 ----- GROUND WIRES .................................................................................................... A/R

29 B9-611-03 STRAIN RELIEF ASSEMBLY, power cord ................................................................... 1

30 B9-611-04 CORD, power ............................................................................................................... 1

31 B1-010-01 FUSE HOLDER ASSEMBLY........................................................................................ 2

32 B9-410-103 FUSE, 250V, 2A, timelag ............................................................................................. 2

 33 B4-342-63 SCREW,phillips,M4x10 ............................................................................................ 4

Skytron AURORA LED Series User Manual
