Page 51
Item Part No. Description Qty.
22. AUR STAND MODEL SUPPORT POST ASSEMBLY
1 B9-210-28 SCREW,phillips,M4x8 .............................................................................................. 2
2 B3-210-04 SLIP RING ................................................................................................................... 1
3 B4-342-52 MOUNT, slip ring .......................................................................................................... 1
4 B9-611-05 SCREW,phillips,athead,M4x8 ........................................................................... A/R
5 B9-611-06 SUPPORT ARM ........................................................................................................... 1
6 B9-611-07 SCREW .................................................................................................................... A/R
7 B5-011-03 SCREW,phillips,M4x12 ............................................................................................ 1
8 B9-611-08 JOINT, upper knuckle ................................................................................................... 1
9 B9-611-09 STOP ........................................................................................................................... 1
10 B4-341-19 PIN,pivot ..................................................................................................................... 2
11 B4-342-55 SCREW,allenhead,countersunk,M4x12 .................................................................. 2
12 B9-611-10 SCREW, set ................................................................................................................. 1
13 B9-611-11 PIN ............................................................................................................................... 1
14 B4-342-71 ROLLER ....................................................................................................................... 2
15 B9-611-12 WASHER ..................................................................................................................... 2
16 B9-611-13 SHAFT, balance ........................................................................................................... 1
17 B4-341-21 GUIDE, bearing, left ..................................................................................................... 1
B4-341-22 GUIDE, bearing, right .................................................................................................. 1
18 B9-611-14 HOUSING, BOM .......................................................................................................... 1
19 B4-342-56 SCREW,allenhead,countersunk,M4x14 .................................................................. 8
20 B4-341-06 COVER, rubber ............................................................................................................ 2
21 B9-611-15 COLLAR, spring ........................................................................................................... 1
22 B9-611-16 SPRING ....................................................................................................................... 1
23 B4-342-25 WASHER, needle bearing............................................................................................ 2
24 B4-342-26 NEEDLE BEARING ..................................................................................................... 1
25 B4-342-27 BUSHING, nylon .......................................................................................................... 1
26 B4-342-28 NUT,springadjustment ................................................................................................ 1
27 B9-611-17 INSERT ........................................................................................................................ 1
28 B9-611-18 STAND POLE ............................................................................................................... 1
29 B1-410-85 HANDLE ...................................................................................................................... 2
30 B4-242-45 HOOK, cord ................................................................................................................. 2
31 B9-611-19 SCREW ........................................................................................................................ 1
32 B9-611-20 PLATE, switch .............................................................................................................. 1
33 B9-611-21 SWITCH, intensity ........................................................................................................ 1
34 B4-242-73-1 SWITCH, main, DPST, green ....................................................................................... 1
35 B5-010-81 SCREW,phillips,M3x6 .............................................................................................. 4
36 B4-211-03 BOLT,allen,M5x10 .................................................................................................... 2
37 B9-611-21-1 SWITCH, color temperature ......................................................................................... 1
To Next Page
