Skytron AURORA LED Series User Manual

INTRODUCTION
 Thismanualcontainstheexplodedviewsandreplacementpartslistsfortheserviceablecomponents
oftheSKYTRONAURORASeriesSurgicalLightingxtures
 Eachserviceablepartintheseexplodedviewsisidentiedbyareferencenumber.Usethisnumber
tolocatenecessarypartinformationinthepartslistadjacenttotheexplodedview.
Always use the complete SKYTRON part number and description when ordering replacement
parts.
Abbreviations
As Required ....................................................... A/R
Optional .............................................................. opt
Serial Number ................................................... S.N.
Not Shown ........................................................... NS
Althoughcurrentattimeofpublication,SKYTRON’spolicyofcontinuousdevelopmentmakesthis
manualsubjecttochangewithoutnotice.
MODEL
(CAT. NO.)
SERIAL NO.
The lighthead Data Label (located on center band of lighthead) and
wall control Data Label (located on the side of wall control case) contain the model
number, bulb type, fuse type, electrical specifications and product serial number.
LIGHTHEAD LABEL
Manufactured for SKYTRON by DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
GRAND RAPIDS, MI · 616.656.2900
INPUT 30V DC
CAT. NO.
ELECTRICAL RATING
BULB TYPE B1-610-38 7W
SERIAL NO. 0000
WALL CONTROL LABEL
Manufactured for SKYTRON by DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
GRAND RAPIDS, MI · 616.656.2900
INPUT 120V~
CAT. NO.
ELECTRICAL RATING
OUTPUT 30V DC
SERIAL NO. 0000
SAFETY FUSE TIMELAG
