Page 37

Item Part No. Description Qty.

15. WALL CONTROL COMPONENTS

 1 B9-610-55 PANEL,wallcontrolfront,LED7orLED5 .................................................................... 1

  B9-610-56 PANEL,wallcontrolfront,LED75orLED55 ................................................................ 1

  B9-610-57 PANEL,wallcontrolfront,LED755orLED555 ............................................................ 1

2 B9-610-82 CIRCUIT BOARD, 20,000 hour indicator ..................................................................... 1

3 B9-610-70 SCREW ........................................................................................................................ 4

4 B9-610-60 SCREW .................................................................................................................... A/R

5 B9-610-61 PLATE, power supply unit, single or dual ..................................................................... 1

B9-610-62 PLATE, power supply unit, triple .................................................................................. 1

6 B9-610-63 POWER SUPPLY UNIT ........................................................................................... A/R

7 B9-510-18 NUT, lock, M4 ........................................................................................................... A/R

8 B4-342-62 WASHER, star, M4 ................................................................................................... A/R

9 B9-610-71 SCREW ........................................................................................................................ 4

10 B9-610-65 FUSE HOLDER ....................................................................................................... A/R

11 B9-610-66 FUSE, 2A timelag .................................................................................................... A/R

12 B9-610-67 SEAL ........................................................................................................................ A/R

13 B9-610-68 CIRCUIT BOARD, single.............................................................................................. 1

B9-610-84 CIRCUIT BOARD, dual ................................................................................................ 1

B9-610-69 CIRCUIT BOARD, triple ............................................................................................... 1

14 B9-610-70 SCREW ........................................................................................................................ 7
