SM ALFOplus - 16 ALFOPLUS 13 GHZ CHARACTERISTICS

164 MN.00273.E - 004
- Rx Spurious emissions according to ETSI EN 301 390
- AGC dynamic range from -22 dBm to Threshold @ BER=10
-6
- Accuracy of Rx level indication @ 25 C° (PC reading)±2dB in the range -22dBm ÷ Thresholds @
BER=10
-6
- Accuracy of Rx level indication over the
whole temperature range (PC reading) ±3dB in the range -50dBm ÷ Thresholds @
BER=10
-6
±4dB in the range -49dBm ÷ -22dBm
- Maximum input level for BER 10-6 -22 dBm
- Residual BER (RBER) 10
-12
- Receiver Dynamic Range (
4
) [dB] see Tab.43
Tab.43 - Receiver Dynamic Range [dB]
15.2.4 Radio flange
- Radio WG flange type UBR 100
28
BER=10
-6
-74.5 -71.5 -68.0 -65.5 -61.5
BER=10
-10
-72.5 -69.5 -66.0 -63.5 -59.5
30
BER=10
-6
-74.0 -71.0 -67.5 -65.0 -61.0
BER=10
-10
-72.0 -69.0 -65.5 -63.0 -59.0
40
BER=10
-6
-73.0 -70.0 -66.5 -64.0 -59.5
BER=10
-10
-71.0 -68.0 -64.5 -62.0 -57.5
56
BER=10
-6
-71.5 -68.5 -65.0 -62.5 -58.0
BER=10
-10
-69.5 -66.5 -63.0 -60.5 -56.0
4 Range over which at least RBER performances are guaranteed (-25dBm ÷ Threshold @ 10
-6
+10dB)
CHANNEL
BANDWIDTH
[MHz]
4QAMs 4QAM 16QAMs 16QAM 32QAM 64QAM 128QAM 256QAM 512QAM 1024QAM
7 58.0 55.5 52.0 49.0 47.0 44.5 41.0 38.5 35.5 32.0
10 57.0 54.0 50.5 47.5 45.5 43.0 39.5 37.0 34.0 30.0
14 57.0 53.5 50.5 47.0 45.0 42.5 39.0 36.0 33.0 29.0
28 54.0 50.5 47.0 44.0 42.5 39.5 36.5 33.0 30.5 26.5
30 53.5 50.0 46.5 43.5 42.0 39.0 36.0 32.5 30.0 26.0
40 52.5 49.0 45.5 42.5 40.5 38.0 35.0 31.5 29.0 24.5
56 51.0 47.5 44.0 41.0 39.0 36.5 33.5 30.0 27.5 23.0
