6.3.1 Ethernet optical interface characteristics
The optical interface can be specialized for the different applications by insertion of the proper transceiver
on the unit.
Tab.9 - Interface characteristics
6.4 POWER SUPPLY AND CABLE
ALFOplus unit is compatible with standard POE + IEEE 802.at (with exceeding maximum power). Power
supply can be provided at the LAN1 (ALFOplus GE) or LAN2 (ALFOplus GO).
In case of external PoE injector, verify that it has overcurrent protection. Power supply can be provided at
the LAN interface or at an auxiliary separated connector at the same time. The maximum length of CAT5e
cable (that carries data+PoE) is 100m.
- Operating voltage range 48Vdc ±15%
- Power consumption
2
see Tab.10
Tab.10 - Power consumption (W)
Parameter
Gigabit 100 Mbit/s
Single Mode Multi Mode Multi Mode
9/125 µm 50/125 µm 62.5/125 µm 50/125 µm 62.5/125 µm
Operating Distance up to 10km up to 550m up to 2km
Optical Center Wavelength 1310 nm 850 nm 1310 nm
Optical Transmit Power -3 ÷ -9.5 dBm -2 ÷ -9.5 dBm -14 ÷ -22 dBm
Receive Sensitivity -19 dBm -17 dBm -29 dBm
Average Receive Power
Max
-3 dBm 0 dBm -14 dBm
Link Power Budget 9.5 dB 7.5 dB 7 dB
Compliance
1000BaseLX
IEEE 802.3z
1000BaseSX
IEEE 802.3z
1000BaseFX IEEE 802.3z
100BaseFx IEEE 802.3z
Transceiver Type Pluggable
Connectors Type LC
2 Power consumption with negligible cable length.
Power consumption (W)
Frequency band Typical Guaranteed
6 t.b.d. t.b.d.
737 39
837 39
11 35 37
