SM ALFOplus - Radio Flange; Power Supply and Consumption; Mechanical Characteristics

MN.00273.E - 004 199
Tab.93 - Receiver Dynamic Range (dB)
19.2.4 Radio flange
- Radio WG flange type UBR 220
19.2.5 Power supply and consumption
- Operating voltage range 48 Vdc ±15%
-Power consumption see Tab.94
Tab.94 - Power consumption
19.2.6 Mechanical characteristics
- Physical size of system components see Tab.95
Tab.95 - Physical size of system components
- Weight of system components 4.3 kg
CHANNEL
BANDWIDTH
[MHz]
4QAMs 4QAM 16QAMs 16QAM 32QAM 64QAM 128QAM 256QAM 512QAM 1024QAM
7 57.5 55.0 51.5 48.5 46.5 44.0 40.5 38.0 36.0 35.0
10 56.5 53.5 51.0 47.0 45.0 42.5 39.0 36.5 33.5 29.5
14 56.5 53.0 50.0 46.5 44.5 42.0 38.5 35.5 33.0 32.5
20 55.0 51.5 48.5 45.0 43.0 40.5 37.0 34.0 31.0 27.0
28 53.5 50.0 46.5 43.5 42.0 39.0 36.0 32.5 30.5 30.0
30 53.0 49.5 46.0 43.0 14.5 38.5 35.5 32.0 29.5 25.5
40 52.0 48.5 45.0 42.0 40.0 37.5 34.5 31.0 28.5 24.0
50 51.0 47.5 44.0 41.0 39.0 36.5 33.5 30.0 27.5 23.0
56 50.5 47.0 43.5 40.5 38.5 36.0 33.0 29.5 27.0 22.5
Typical Power
Consumption (W)
Guaranteed Power
Consumption (W)
33.5  35
Width (mm) Height (mm) Depth (mm)
270.4 287.3 154.6
