SM ALFOplus - Waveguide Flange

50 MN.00273.E - 004
6.5 WAVEGUIDE FLANGE
-Type see Tab.16
Tab.16 - Type
- Maximum length see.Tab.17
Tab.17 - Maximum length
Frequency band Type
6 UDR 70
7UBR 84
8UBR 84
11 UBR 100
13 UDR 120
15 UDR 140
18 UBR 220
23 UBR 220
26 UBR 220
32 UBR 320
38 UBR 320
42 UBR 500
Waveguide maximum length
Channel spacing (m)
7 MHz 10
14 MHz 10
28 MHz 10
40 MHz 5
56 MHz 5
