TP303 - Operation, Maintenance and Instructions Manual
1.2
NOTE
Make sure that arrow engraved on the magnet coincides with the arrow engraved on the position transmitter
when the system is in mid travel. The magnet mounting in relation to the hall sensor:
1 . Must not have attrict between the internal magnet face and the hall sensor salience during the travel
(rotary or linear), through the magnet.
2. The magnet and the salience of hall sensor must not be distant.
A minimum distance of 2mm and a maximum distance of 4mm is recommended between the magnet external
face and the position transmitter face.
Should the installation of the transmitter or magnet be altered, or should there be any other
modification, the transmitter will require a re-calibration.
