5.2
Temperature Effect
± 0.8%/20ºC of F.S.
Power Supply Effect
± 0.005% of calibrated F.S. per volt.
Electro-Magnetic Interface Effect
Designed to comply with IEC 801 and European Standards EN50081 and EN50082.
Physical Specifications
Hardware
Physical: according to IEC 61158-2 and conformity with the FISCO model.
Electrical Connection
½ - 14 NPT, Pg 13.5, or M20 x 1.5 metric.
Material of Construction
Injected low copper aluminum with polyester painting or 316 stainless steel housing, with Buna-N
o-rings on cover (NEMA 4X, IP67).
Mounting Bracket
Plated carbon steel with polyester painting or 316 SST.
Identification Plate
316 SST.
Approximate Weights
Without display and mounting bracket: 0.80 kg.
Add for LCD display: 0.13 kg.
Add for mounting bracket: 0.60 kg.
Ordering Code
MODEL PROFIBUS PA POSITION TRANSMITTER
COD.
LOCAL INDICATOR
1 With Digital Indicator
COD.
MOUNTING BRACKET
0
1
Without Bracket
With Bracket
COD.
ELECTRICAL CONNECTIONS
0
A
B
1/2 - 14 NPT
M20 x 1.5
PG 13.5 DIN
COD.
TYPE OF MOTION
1
3
5
7
Z
Rotary
Linear stroke up to 15 mm
Linear stroke up to 50 mm
Linear stroke up to 100 mm
Others (specify)
COD.
OPTIONAL ITEMS*
H0
H1
H2
H3
H4
R1
R2
R3
R4
ZZ
Housing - Aluminum (IP/Type)
Housing - 316 Stainless Steel (IP/Type)
Housing - Aluminum for saline atmosphere (IPW/Type X)
Housing - 316 Stainless Steel for saline atmosphere (IPW/Type X)
Housing - Copper Free Aluminum (IPW/Type X)
Remote sensor - 5 m. Cable (**)
Remote sensor - 10 m. Cable (**)
Remote sensor - 15 m. Cable (**)
Remote sensor - 20 m. Cable (**)
With special features (specify)
Typical Model
* Leave it blank for no optional items.
** Consult Smar for applications in classified areas.
TP303 1 0 0 1 *
