TP303 – Operation, Maintenance and Instructions Manual
3.4
Transducer Block Parameter Attributes
Relative
Index
Parameter Mnemonic
Object
Type
Data Type
S
t
o
r
e
Size Access
Parameter
usage/
Type of
transport
Default
value
Download
Order
Mandatory
Optional
(Class)
... Standard Parameter
Additional Parameter for Transducer Block
8 SENSOR_VALUE Simple Float D 4 r C/a 0 - M (B)
9 SENSOR_HI_LIM Simple Float N 4 r C/a 0 - M (B)
10 SENSOR_LO_LIM Simple Float N 4 r C/a 0 - M (B)
11 CAL_POINT_HI Simple Float N 4 r,w C/a 100.0 - M (B)
12 CAL_POINT_LO Simple Float N 4 r,w C/a 0.0 - M (B)
13 CAL_MIN_SPAN Simple Float N 4 r C/a 0 - M (B)
14 MAINT_DATE Simple Octet String S 16 w,w C/a O(B)
15 SENSOR_UNIT Simple Unsigned 16 N 2 r,w C/a 1342 - M (B)
16 SENSOR_SN Simple Unsigned 32 N 4 r,w C/a - M (B)
17 TRIMMED_VALUE Record DS-33 D 5 r C/a 0.0 - M (B)
18 PRIMARY_VALUE Record DS-33 D 5 r C/a 0.0 - M (B)
19 PRIMARY_VALUE_UNIT Simple Unsigned 16 N 2 r,w C/a - - M (B)
20 PRIMARY_VALUE_TYPE Simple Unsigned 16 N 2 r,w C/a 255 - M (B)
21 SECONDARY_VALUE_1 Record DS-33 D 5 r C/a 0.0 - O (B)
22 SECONDARY_VALUE_1_UNIT Simple Unsigned 16 N 2 r,w C/a E.U. - O (B)
23 SECONDARY_VALUE_2 Record DS-33 D 5 r C/a 0 - O (B)
24 SECONDARY_VALUE_2_UNIT Simple Unsigned 16 N 2 r,w C/a % - O (B)
25 SCALE_IN Array Float S 8 r,w C/a 100.0 0.0 - O(B)
26 SCALE_OUT Array Float S 8 r,w C/a 100.0 0.0 - O(B)
27 MAX_SENSOR_VALUE Simple Float N 4 r,w C/a 0.0 - O (B)
28 MIN_SENSOR_VALUE Simple Float N 4 r,w C/a 0.0 - O (B)
29 SECONDARY_VALUE Record DS-33 D 5 r C/a 0.0 - O (B)
30 SECONDARY_VALUE_UNIT Simple Unsigned 16 N 2 r C/a Celsius - O (B)
31 CAL_TEMPERATURE Simple Float N 4 r,w C/a Celsius O (B)
32 DIGITAL_HALL Record DS-33 D 5 r C/a 0.0 - O (B)
33 DIAGNOSTIC_STATUS Simple Unsigned 16 D 2 r C/a 0x0001 - O (B)
34 READ_HALL_CAL_POINT_HI Simple Float N 4 r C/a O (B)
35 READ_HALL_CAL_POINT_LO Simple Float N 4 r C/a O (B)
36 ACTION_TYPE Simple Unsigned 8 S 1 r,w C/a direct - O (B)
37 BACKUP_RESTORE Simple Unsigned 8 S 1 r,w C/a 0 - O (B)
38 XD_ERROR Simple Unsigned 8 D 1 r C/a 0x10 - O (B)
39 MAIN_BOARD_SN Simple Unsigned 32 S 4 r,w C/a 0 - O (B)
40 EEPROM_FLAG Simple Unsigned 8 D 1 r C/a FALSE - O (B)
41 ORDERING_CODE Array Unsigned 8 S 50 r,w C/a - - O (B)
Table 3.2 - Transducer Block Parameter Attributes
