SMAR TP303 User Manual

Configuration
3.5
Transducer Block View Object
Relative Index Parameter Mnemonic View_1 View_2 View_3 View_4
1
ST_REV
2
2
TAG_DESC
3
STRATEGY
4
ALERT_KEY
5 TARGET_MODE
6
MODE_BLK
3
7
ALARM_SUM
8
8 SENSOR_VALUE
9
SENSOR_HI_LIM
10
SENSOR_LO_LIM
11 CAL_POINT_HI
12
CAL_POINT_LO
13
CAL_MIN_SPAN
14
MAINT_DATE
15
SENSOR_UNIT
16
SENSOR_SN
17
TRIMMED_VALUE
18 PRIMARY_VALUE 5
19
PRIMARY_VALUE_UNIT
20
PRIMARY_VALUE_TYPE
21 SECONDARY_VALUE_1
22
SECONDARY_VALUE_1_UNIT
23
SECONDARY_VALUE_2
24
SECONDARY_VALUE_2_UNIT
25
SCALE_IN
26
SCALE_OUT
27
MAX_SENSOR_VALUE
28 MIN_SENSOR_VALUE
29
SECONDARY_VALUE
30
SECONDARY_VALUE_UNIT
31
CAL_TEMPERATURE
32
DIGITAL_HALL
33
DIAGNOSTIC_STATUS
34
READ_HALL_CAL_POINT_HI
35 READ_HALL_CAL_POINT_LO
36
ACTION_TYPE
37
BACKUP_RESTORE
38 XD_ERROR
39
MAIN_BOARD_SN
40
EEPROM_FLAG
41
ORDERING_CODE
TOTAL
13 + 5 = 18 bytes
Table 3.3 - View Objects
