Appendices
Appendices

Y/Pb/Prsignals
Signal format fh (kHz) fv (Hz)
480i (525i) @ 60 Hz 15.73 59.94
480p (525p) @ 60 Hz 31.47 59.94
576i (625i) @ 50 Hz 15.63 50
576p (625p) @ 50 Hz 31.25 50
720p (750p) @ 60 Hz 45 60
720p (750p) @ 50 Hz 37.5 50
1080i (1125i) @ 60 Hz
33.75 60
1080i (1125i) @ 50 Hz 28.13
50
1080p (1125p) @ 60 Hz
67.5 60
1080p (1125p) @ 50 Hz
56.25 50

S-VideoandCompositeVideosignals
Videomode fh (kHz) fv (Hz) fsc (MHz)
NTSC 15.73 60 3.58
PAL 15.63 50 4.43
SECAM 15.63 50 4.25 or 4.41
PAL-M 15.73 60 3.58
PAL-N 15.63 50 3.58
PAL-60 15.73 60 4.43
NTSC4.43 15.73 60 4.43
