49 English
Appendices
Appendices
RS-232 Connector Pin Assignments
Pin no. Spec.
1 N/A
2 TXD
3 RXD
4 N/A
5 GND
6 N/A
7 N/A
8 N/A
9 +9VDC
54321
9876
