DISPLAY OF THE
MEASURED
VALUES
T E M P e r a t u r e
5 0 c
a n a l o g o u t = 2 5 %
A U T O M A T I C H
r e l a i s r 1 = 0
r 2
= 0 r 3 = 1 r 4 = m
Temperature
If a suitable sensor is connected to the PT1000 interface, the measured temperature
is displayed here.
Analogue out
ANALOGOUT = 25%. The current level of the analogue output is
displayed. There are 3
operating modes available:
1.
Switched off: The output is switched off and is not controlled.
2.
Automatic: The output is automatically controlled by the SMARTFOX
depending on the surplus situation.
3.
Manual: The output can be set to a pro- cess value regardless of the surplus
situation.
ATTENTION! Energy can be drawn from the mains.
Relay
RELAY R1-R4: The current switching state of the relay is displayed. There are 3 operating
modes available:
0: The relay is switched off.
1: The set switch-on condition is fulfilled, the relay has been switched on by the SMARTFOX
.
M: The relay can be switched on regardless of the surplus situation.
ATTENTION! Energy can be drawn from the mains.
16
To Next Page
