Smartgen HFC6100LT User Manual

HFC6100LT Fan Controller User Manual Page 12 of 24
No.
Function
Cable Size
Remark
16
COM2
1.5mm
2
PWM 1-4 output common
ports
Connect to positive of
battery.
17
PWM Output 1
1.0mm
2
B+ is supplied by 16 points,
rated 8A
Transistor output rated 1A.
18
PWM Output 2
1.0mm
2
19
PWM Output 3
1.0mm
2
20
PWM Output 4
1.0mm
2
21
Aux. Input 1
1.0mm
2
Connect to GND(B-)
22
Aux. Input 2
1.0mm
2
Connect to GND(B-)
23
Aux. Input 3
1.0mm
2
Connect to GND(B-)
24
Aux. Input 4
1.0mm
2
Connect to GND(B-)
25
Aux. Input 5
1.0mm
2
Connect to GND(B-)
26
Aux. Input 6
1.0mm
2
Connect to GND(B-)
27
Aux. Input 7
1.0mm
2
Connect to GND(B-)
28
Aux. Input 8
1.0mm
2
Connect to GND(B-)
29
Aux. Input Common Port
The controller interior has been connected to power input B-.
30
Aux. Input 9
1.0mm
2
Connect to GND(B-)
31
Aux. Input 10
1.0mm
2
Connect to GND(B-)
32
Aux. Input 11
1.0mm
2
Connect to GND(B-)
33
Aux. Input 12
1.0mm
2
Connect to GND(B-)
34
Aux. Input 13
1.0mm
2
Connect to GND(B-)
35
Aux. Input 14
1.0mm
2
Connect to GND(B-)
36
Aux. Input 15
1.0mm
2
Connect to GND(B-)
37
Aux. Input 16
1.0mm
2
Connect to GND(B-)
38
Aux. Input 17
1.0mm
2
Connect to GND(B-)
39
Aux. Input 18
1.0mm
2
Connect to GND(B-)
40
Aux. Input Common Port
The controller interior has been connected to power input B-.
41
RS485+
0.5mm
2
Impedance-120Ω shielding wire is recommended and
its single end grounded.
42
RS485-
0.5mm
2
43
Terminal Resistor (120Ω)
0.5mm
2
If impedance-120Ω is needed, short connected
terminal 41、43.
44
Sensor 1 Input
1.0mm
2
Connect to temp. sensor 1.
45
Sensor 2 Input
1.0mm
2
Connect to temp. sensor 2.
46
Sensor 3 Input
1.0mm
2
Connect to temp. sensor 3.
47
Sensor 4 Input
1.0mm
2
Connect to temp. sensor 4.
48
Sensor 5 Input
1.0mm
2
Connect to temp. sensor 5.
49
Sensor Common Port
/
Sensor common port
The controller interior has been connected to power
input B-.
