3 SPECIFICATION
Table 2 – Performance Parameters
Items
Contents
Working Voltage
Continuous power supply: DC8.0V to DC35.0V
Power Consumption
<4W(Standby mode: ≤2W)
AUX. Output 1~12
1A DC24V Transistor B+ output
PWM 1-4
1A DC24V Transistor B+ output
Frequency 100Hz
Duty Ratio 0~100%
Digital Input 1-16
Low threshold voltage is 2.8V; high limit voltage is 60V
Digital Input 17-18
Low threshold voltage is 1.2V; high limit voltage is 60V
RS485
Isolated, half-duplex, 9600 baud rate,
maximum communication length 1000m
Vibration
5 - 8 Hz: ±7.5 mm
8 - 500 Hz: 2 g
IEC 60068-2-6
Shock
50g, 11ms, half-sine, complete shock test from three directions, and
18 times shock for each test
IEC 60068-2-27
Bump Test
25g, 16ms, half-sine
IEC 60255-21-2
Production Compliance
According to EN 61010-1 installation category (over voltage
category) III, 300V, pollution class 2, altitude 3000m
Overall Dimensions
209mm x 167mm x 45mm
Panel Cutout
186mm x 141mm
Working Condition
Temperature: (-40~+70)ºC Relative Humidity: (20~93)%RH
Storage Condition
Temperature: (-40~+80)ºC
Protection Level
Front panel: IP65, when waterproof gasket ring inserted between
panel and housing.
Rear panel:IP20
Weight
0.6kg
