HFC6100LT Fan Controller User Manual Page 13 of 24
7 PARAMETER RANGE AND DEFINITION
7.1 PARAMETER CONTENT AND RANGE
Table 7 – Parameter Content and Range
No.
Item
Range
Default
Remark
1
Battery Over Voltage
Alarm Threshold
(12.0-40.0)V
33.0
When battery voltage is higher than this
value and lasts for 20s, controller will
send battery high voltage alarm signal.
2
Battery Under Voltage
Alarm Threshold
(4.0-30.0)V
8.0
When battery voltage is lower than this
value and lasts for 20s, controller will
send battery low voltage alarm signal.
3
Manually Set PWM
Period
(0-100)%
10
Manual fan speed mode, press speed-up
or speed-down key, the PWM period will
be adjusted.
4
Sensor 1 Curve
Selection
(0-15)
10
PT100, refer to Table 8.
5
Sensor 1 Open Circuit
(0-1)
0
0: Inactive 1: Alarm
6
Sensor 1 High Alarm
Threshold Value
(0-300)℃
95
When the temperature of external temp.
sensor is higher than this value, it will
send high temperature signal. When the
setting value is equal to 300, it will not
send the signal.
7
Sensor 1 Control Fan
Groups
(0-5)
1
1 group of fan controlled.
8
Sensor 1 Custom
Curve
Custom temperature sensor curve (X: Resistance Y:
Temperature).
9
Sensor 1 Fan Control
Curve
Custom fan control curve (X: Temperature Y: Number of fan
output)
10
Return Difference
Value of Sensor 1
(0-300)℃
5
During the fan output control process,
temperature difference required when the
fan output is turned off.
11
Sensor 2 Curve
Selection
(0-15)
10
PT100, refer to Table 8.
12
Sensor 2 Open Circuit
(0-1)
0
0: Inactive 1: Alarm
13
Sensor 2 High Alarm
Threshold Value
(0-300)℃
95
When the temperature of external temp.
sensor is higher than this value, it will
send high temperature signal. When the
setting value is equal to 300, it will not
send the signal.
14
Sensor 2 Control Fan
Groups
(0-5)
2
2 groups of fan controlled.
15
Sensor 2 Custom
Curve
Custom temperature sensor curve (X: Resistance Y:
Temperature).
16
Sensor 2 Fan Control
Curve
Custom fan control curve (X: Temperature Y: Number of fan
output)
