Smartgen HFC6100LT User Manual

HFC6100LT Fan Controller User Manual Page 15 of 24
No.
Item
Range
Default
Remark
35
Sensor 5 Control Fan
Groups
(0-5)
5
5 groups of fan controlled.
36
Sensor 5 Custom
Curve
Custom temperature sensor curve (X: Resistance Y:
Temperature).
37
Sensor 5 Fan Control
Curve
Custom fan control curve (X: Temperature Y: Number of fan
output)
38
Return Difference
Value of Sensor 5
(0-300)℃
5
During the fan output control process,
temperature difference required when the
fan output is turned off.
39
Aux. Output 1 Setting
(0-25)
1
Factory default: 1 group of fan control
output. Refer to Table 9
40
Output 1 Type
(0-1)
0
0: Normally open; 1: Normally close.
41
Aux. Output 2 Setting
(0-25)
1
Factory default: 1 group of fan control
output. Refer to Table 9
42
Output 2 Type
(0-1)
0
0: Normally open; 1: Normally close.
43
Aux. Output 3 Setting
(0-25)
1
Factory default: 1 group of fan control
output. Refer to Table 9
44
Output 3 Type
(0-1)
0
0: Normally open; 1: Normally close.
45
Aux. Output 4 Setting
(0-25)
1
Factory default: 1 group of fan control
output. Refer to Table 9
46
Output 4 Type
(0-1)
0
0: Normally open; 1: Normally close.
47
Aux. Output 5 Setting
(0-25)
2
Factory default: 2 groups of fan control
output. Refer to Table 9
48
Output 5 Type
(0-1)
0
0: Normally open; 1: Normally close.
49
Aux. Output 6 Setting
(0-25)
2
Factory default: 2 groups of fan control
output. Refer to Table 9
50
Output 6 Type
(0-1)
0
0: Normally open; 1: Normally close.
51
Aux. Output 7 Setting
(0-25)
3
Factory default: 3 groups of fan control
output. Refer to Table 9
52
Output 7 Type
(0-1)
0
0: Normally open; 1: Normally close.
53
Aux. Output 8 Setting
(0-25)
3
Factory default: 3 groups of fan control
output. Refer to Table 9
54
Output 8 Type
(0-1)
0
0: Normally open; 1: Normally close.
55
Aux. Output 9 Setting
(0-25)
4
Factory default: 4 groups of fan control
output. Refer to Table 9
56
Output 9 Type
(0-1)
0
0: Normally open; 1: Normally close.
57
Aux. Output 10 Setting
(0-25)
4
Factory default: 4 groups of fan control
output. Refer to Table 9
58
Output 10 Type
(0-1)
0
0: Normally open; 1: Normally close.
59
Aux. Output 11 Setting
(0-25)
5
Factory default: 5 groups of fan control
output. Refer to Table 9
60
Output 11Type
(0-1)
0
0: Normally open; 1: Normally close.
61
Aux. Output 12 Setting
(0-25)
5
Factory default: 5 groups of fan control
output. Refer to Table 9
