HGM501 Genset Controller User Manual Page 6 of 17
3. TECHNICAL DATA
Table 2 – Technical Data
Parameter
Details
Operating voltage
DC9.0V to 18V uninterrupted power supply - DC12V system
used
Overall consumption
<2W (Standby mode ≤1W)
Alternator voltage inputs:
Single phase 2-wire (L and N
only)
2-phase 3-wire (L and N only)
3-phase 4-wire (L and N only)
AC 30V - 360V (ph-N)
AC 30V - 360V (ph-N)
AC 30V - 360V (ph-N)
Alternator frequency
50/60Hz
Start relay output
7A DC12V power supply output
Fuel relay output
7A DC12V power supply output
Case dimensions
118 mm x 128 mm x 36 mm
CT Secondary current
Rated 62.5mA
Operating Temperature
(-25~+70)°C
Operating Humidity
(20~90)%RH
Storage Temperature
(-30~+80)°C
Protection level
IP42
Insulation strength
Apply AC1.5kV voltage between high voltage terminal and
low voltage terminal;
The leakage current is not more than 3mA within 1min.
Weight
0.216kg
