Smartgen MGC100 User Manual

MGC100 Petrol Genset Controller User Manual Page 6 of 16
3 SPECIFICATION
Table 3 Technical Parameters
Item
Contents
Working Voltage
DC9.0V to 18.0V, continuous power supply (suitable for DC12V
system)
Overall Consumption
Regular working:<1W (Standby mode:<0.4W)
AC Volt Input:
3-phase 4-wire
3-phase 3-wire
2-phase 3-wire
Single phase 2-wire
AC 30V – AC 360V (ph-N)
AC 50V – AC 620V (ph-ph)
AC 30V – AC 360V (ph-N)
AC 30V – AC 360V (ph-N)
AC Frequency
50Hz/60Hz
Speed Sensor Voltage
1.0V to 24V(effective value)
Speed Sensor Frequency
10000Hz(Max)
Start Relay
7A DC12V power supply
Fuel Relay
7A DC12V power supply
Flexible Transistor
1A DC12V connect to (B+)
Overall Dimensions
105.8mm x 61mm x 36.6mm
Panel Cutout
92mm x 44mm
Working Temperature
(-25~+70)°C
Working Humidity
(20~93)%RH
Storage Temperature
(-25~+70)°C
Protection Level
IP55 Gasket
Insulation
Apply AC2.2kV voltage between high voltage terminal and low
voltage terminal; The leakage current is not more than 3mA within
1min.
Weight
94g
