MGC100 Petrol Genset Controller User Manual Page 11 of 16
7 DEFINITION AND RANGE OF PARAMETERS
Table 7 Parameter Content and Range
No.
Content
Parameter Range
Default
Description
P00
AC
(0-3)
0
0: Single phase 2-wire
1: 2-phase 3-wire
2: 3-phase 3-wire
3: 3-phase 4-wire
P01
Over Volt Threshold
(30-620)V
264
When generate voltage exceed this value and
last for “Abnormal Delay”, then it is regarded as
over voltage and at the same time “Gen
Abnormal” signal will be sent. When set value
is 620V, it won’t detect over voltage signal.
P02
Under Volt
Threshold
(30-620)V
196
When generate voltage is under this value and
last for “Abnormal Delay”, then it is regarded as
under voltage and at the same time “Gen
Abnormal” signal will be sent. When set value
is 30V, it won’t detect under voltage signal.
P03
Gen Abnormal
Delay
(0-20)s
10
Alarm delay value of generate over or under
voltage.
P04
Start Delay
(0-3600)s
1
Time from remote start signal is active to start
the genset.
P05
Stop Delay
(0-3600)s
1
Time from remote stop signal is deactivated to
stop the genset.
P06
Start Attempts
(1-10)times
3
It is maximum of start attempts when starter
failed to start. When reach set attempts the fail
to start alarm will be initiated.
P07
Preheat Delay
(0-300)s
0
Time of pre-powering heat plug before starter
is powered up.
P08
Crank Time
(3-60)s
8
Time of starter power up.
P09
Crank Rest Time
(3-60)s
10
The waiting time before second power up when
engine start fail.
P10
Safety On Time
(1-60)s
5
Alarms for low oil pressure and under voltage
are inactive.
P11
Start Idle Time
(0-3600)s
0
Idle running time of genset when starting.
P12
Warming Up Time
(3-3600)s
10
Warming time between genset close and high
speed running.
P13
Cooling Time
(3-3600)s
10
Radiating time before stop genset, after it
unloads.
P14
Stop Idle Time
(0-3600)s
0
dle running time when pump unit stop.
P15
ETS Hold Time
(0-120)s
20
Stop electromagnet’s power on time when
pump unit is stopping.
P16
Stop Time
(0-120)s
0
Time between ending of pump unit idle delay
and stopped when “ETS Time” is set as 0;
Time between ending of ETS hold delay and
