MGC100 Petrol Genset Controller User Manual Page 12 of 16
No.
Content
Parameter Range
Default
Description
stopped when “ETS Time” is not 0.
P17
Flywheel Teeth
(10-300)
118
Teeth number of the engine, for judging of
starter separation conditions and inspecting of
engine speed. See the following Installation
Instruction.
P18
Over Speed
Threshold
(0-6000)r/min
3500
When rotate speed exceed this threshold and
last over the delay value, over speed shutdown
alarm signal will be sent.
(No detection for over speed signals if it is set
as 0).
P19
Over Speed Delay
(0-20)s
2
When rotate speed exceed over speed
threshold and last over the delay value, over
speed alarm signal will be sent.
P20
Poles
(2-16)
2
Set genset poles.
P21
Disc. Condition
(0-2)
1
Disconnected condition. Separate condition of
starter and engine are gen sensor and
magnetic sensor, in order that separate stater
motor and engine as soon as possible.
P22
Disc. Speed
(0-6000)r/min
840
In starting process, if genset rotate speed
exceed this value, it is regarded as genset start
success, starter will separate.
P23
Disc. Freq
(10-30)Hz
14
In starting process, if genset frequency exceed
this value, that is genset start success, starter
will separate.
P24
Fuel Output Select
(0-1)
0
0: Fuel output; 1: Stop output (ETS Output).
P25
Aux. Output 1
(0-9)
5
Configuration see form “Aux. Output
Defination”
P26
Gen Under Freq
Threshold
(0-75.0)Hz
45.0
When gen frequency falls below this threshold
and last over the delay value, under frequency
shutdown alarm signal will be sent.
(No detection for under frequency signals if it
is set as 0).
P27
Under Freq
Shutdown Delay
(0-60)s
10
Gen under frequency delay value.
P28
Gen Over Freq
Threshold
(0-75.0)Hz
57.0
When gen frequency exceeds this threshold
and last over the delay value, over frequency
shutdown alarm signal will be sent.
(No detection for over frequency signals if it is
set as 0)
P29
Over Freq
Shutdown Delay
(0-60)s
2
Gen over frequency delay value.
CLb1
Ua
Correct A phase voltage value.
CLb2
Ub
Correct B phase voltage value.
CLb3
Uc
Correct C phase voltage value.
