MGC100 Petrol Genset Controller User Manual Page 13 of 16
No.
Content
Parameter Range
Default
Description
CLb4
Uab
Correct AB wire voltage.
CLb5
Ubc
Correct BC wire voltage.
CLb6
Uca
Correct CA wire voltage.
Table 8 Defined Contents of Aux. Output Ports
No.
Content
Description
0
Not Used
When this is chosen, output port won’t output.
1
Preheat Output
Close before start, open before energize.
2
Common Alarm
When stop alarm is initiated, this alarm will self-lock untill alarm reset.
3
Idle Output
Used for engine which has idles. Close before starting and open in
warming up delay; Close during stopping idle process and open when stop
is completed.
4
ETS Output
Used for some genset which has stop electromagnet. Close before
stoping idle ended. Open when “ETS Delay” ended.
5
Air Flap Choke
Used for genset with choke valve electromagnet. Close when gen start
and open when safety running delay is over.
6
Reserved
7
Reserved
8
Reserved
9
Reserved
Table 9 Crank Disconnect Conditions Selection
No.
Content
0
Magnetic Sensor
1
Generator
2
Magnetic Sensor + Generator
NOTE:
1) Magnetic sensor is magnetic device which detects numbers of flywheel teeth installed in generator.
2) If magnetic sensor is selected, please insure numbers of flywheel teeth is same with set value, otherwise,
“Over Speed Shutdown” may be caused.
3) If genset without magnetic sensor, please don’t select corresponding items, otherwise, “Start Failure” may be
caused.
4) If generate isn’t selected, the controller won’t detect over/under voltage; if magnetic sensor isn’t selected,
speed of genset is converted via generate signal.
