FLEXIBLE ASSEMBLY SYSTEM FAS200
User Manual for FAS200 - 41 -
FAS-206 HYDRAULIC PRESS TRANSFERING MODULE
Figure 44: FAS206 Hydraulic Press Transfering Module.
FUNCTION OF THE MODULE:
This sixth module is complementary to
previous one. Is in this module where the
base-bearing assembly is transfered from the
pallet of the lineal conveyor to the platform of
this module, and then from this platform to the
hydraulic press of the previous module.
Figure 45: Manipulators of the sixth module.
