FLEXIBLE ASSEMBLY SYSTEM FAS200
User Manual for FAS200 - 45 -
FAS-207 SHAFT CLASSIFICATION MODULE
Figure 48: FAS207 Shaft
Classification Module.
FUNCTION OF THE MODULE:
This module follows the process needed to insert a shaft into the bearing fitted
at one of the previous modules.
The need for appropriate checks to determine which
type of shaft is to be assembled at each module cycle
means that this module is one of the most complex in
terms of the operations to be carried out. It is also
essential that the module control coordinates part
selection operations in accordance with the
commands supplied by the master responsible for
production management in the FAS-200.
Figure 49: Manipulators of this module.
