FLEXIBLE ASSEMBLY SYSTEM FAS200
User Manual for FAS200 - 44 -
Press feed manipulation
Actuators:
- Double-acting pusher cylinders Ø12, Stroke: 125mm (CD85N12-125A), with
flow regulators and initial-end of stroke position detectors. Controlled by 5/2 way
monostable solenoid valves.
Sensors:
- Reed type magnetic detectors (D-A73CL).
Electrical control panel:
- Mounted on perforated mesh.
- Accessible terminal plate with supply connections and coded I/Os.
- I/O station: 14 digital inputs, 7 outputs.
- Supply module: 24V/60W.
- PLC control:
• CPU with digital inputs/outputs.
• Communication module for PLC network connection.
