FLEXIBLE ASSEMBLY SYSTEM FAS200
User Manual for FAS200 - 50 -
Actuators:
- 2 Double-acting cylinders Ø10, Stroke: 10mm (C85N10-10). Controlled by 5/2
way monostable solenoid valve.
Shaft orientation checker
Actuators:
- Double-acting cylinder Ø12, Stroke: 50mm (CD85N12-50A), with flow
regulators and end position detector. Controlled by 5/2 way monostable
solenoid valve.
Sensors:
- Reed type magnetic detector (D-A73CL).
Material detectors
Sensors:
- Inductive sensor: OMRON (E2A-M18KS08-WP).
- Capacitive sensor: OMRON (E2K-X4MF1).
Electrical control panel:
- Mounted on perforated mesh.
- Accessible terminal plate with supply connections and coded I/Os.
- I/O station: 8 inputs, 6 outputs.
- Supply module: 24V/60W
- PLC control:
• CPU with digital inputs/outputs and counter inputs.
• Communication module for PLC network connection.
